Application description, the scope
Net-style, spiral feed packing scale is developed by our company for powder, flakes and other poor mobility, no corrosion or corrosion of the material packing scale ,it is the most suitable packing scale on the market for poor liquidity material. So far, the series has been packed off packaging materials include: potassium chloride, potash, potassium magnesium, rare earth, flour, ammonium sulfate crystals, soda ash, etc.
Net-style, spiral feed packing scale can be used in a typical packaging material also include: ammonium bicarbonate, ammonium nitrate powder, soybean meal, cement additives, lime, gypsum powder, fish, livestock and poultry feed.
Performance indicators:
|
Model
|
DCS-50NSB
(Single Scale)
|
DCS-50NDB
(Double scale)
|
DCS-50NTB
(Triple Scale)
|
|
Packaging efficiency(bags / hour)
|
300～400
|
600～800
|
900～1200
|
|
Weighing range (kg / pack)
|
20～100
|
20～100
|
20～100
|
|
Precision
|
X(0.1),X(0.2)
|
X(0.1),X(0.2)
|
X(0.1),X(0.2)
|
|
Power supply
|
380VAC ±15％50Hz ±2％
|
380VAC ±15％50Hz ±2％
|
380VAC ±15％50Hz ±2％
|
|
Power
|
5.0kw
|
10.0kw
|
15.0kw
|
|
Compressed air pressure
|
≥0.6MPa
|
≥0.6MPa
|
≥0.6MPa
|
|
Compressed air consumption
|
80 (l / min)
|
130 (l / min)
|
130 (l / min)
|
|
Working environment
|
-20℃～+65℃
|
-20℃～+65℃
|
-20℃～+65℃
|
|
